WAGO 280-510 Triple-Deck Terminal Blocks

SKU#:

58866

WAGO rail-mount terminal block program with proven CAGE CLAMP® Connection Technology has the right terminal block for any application: fuse, disconnect/test, diode and LED terminal blocks, pluggable terminal blocks - even rail-mount terminal blocks for wiring sensors and actuators. Advantages include: Multilevel terminal blocks: Double-deck or triple-deck terminal blocks save space, WAGO 280-510 CAGE CLAMP® connections: tried-and-tested billions of times, Multifaceted, individual commoning options via push-in type jumper bars, step-down jumpers, staggered jumpers, vertical jumpers, etc., Circuit identification via WMB markers, Easy testing via pluggable and modular test plug adapters, as well as test plugs.
Specifications
Brand WAGO
Manufacturer Part Number 280-510
Manufacturer Alternate Number 51245274
UPC 4050821293552
Electrical Connection CAGE CLAMP®
Fine-Stranded Conductor Wire Range 0.08mm2 - 2.5mm2 / 28 - 12 AWG
Total Number of Connection Points 6
Total Number of Potentials 3
Strip Length 8mm - 9mm / 0.31 - 0.35 inch
Number of Levels 3
Type of Wiring Front-Entry Wiring
Mounting Type DIN-35 Rail
Color Green-Yellow, Blue, Gray
Height (mm) 49.5mm / 1.949 inch
Width (mm) 5mm / 0.197 inch
Depth (Length) (mm) 103mm / 4.055 inch
Weight (lbs) 0.05
UOM ea
