Omron D2SW-3L3HS Roller Lever Snap Action Switches

SKU#:

788

Sealed subminiature basic switch conforming to IP67 (excluding the terminals on terminal models). Use of epoxy resin assures stable sealing, making this Omron switch ideal for places subject to water spray or excessive dust. D2SW-3L3HS is ideal for automobiles, automatic vending machines, refrigerators, ice-making equipment, bath equipment, hot-water supply systems, air conditioners, and industrial equipments, which require high environmental resistance. Models available with UL, CSA, and VDE safety standard compliance.
Specifications
Brand Omron Automation
Manufacturer Part Number D2SW-3L3HS
Manufacturer Alternate Number D2SW3L3HS
UPC 4536853193225
Terminal Type Solder Terminal
Rated Current 3A
Actuator Type Simulated Roller Hinge Lever
Switch Type SPDT
Electrical Operations Minimum 200,000 Operations
Mechanical Operations Minimums 5,000,000 Operations
Mounting Type Chassis 2.4mm Hole
IP Rating IP67
Type Subminiature Basic
Height (mm) 13mm
Width (mm) 19.8mm
Depth (Length) (mm) 5.9mm
Weight (lbs) 0.01
UOM ea
