Omron EE-SY671 Reflective Photomicrosensor
SKU#:
999
Omron optical Sensors provide a compact, low-cost method to detect workpieces. Many models are available, including Slot-type Sensors (through-beam) for non-modulated or modulated light, Reflective Sensors, and Sensors with separate emitters and receivers. With Reflective Sensors like EE-SY671, light is shown on the workpiece and reflected light is detected.
| Brand | Omron Automation |
|---|---|
| Manufacturer Part Number | EE-SY671 |
| Manufacturer Alternate Number | EESY671 |
| UPC | 4536853238780 |
| Type | Horizontal |
| Operation | Light-ON, Dark-ON Selectable |
| Supply Voltage Range | 5VDC - 24VDC |
| Material | PBT |
| Sensing Method | Reflective |
| Sensing Range | 1mm - 5mm |
| Output Type | NPN |
| Light Source | GaAs infrared LED |
| IP Rating | IP50 |
| Height (mm) | 31.4mm |
| Width (mm) | 25.4mm |
| Depth (Length) (mm) | 6.95mm |
| Weight (lbs) | 0.01 |
| UOM | ea |
