SICK LBSR40900 7020052 Area Detection Glass Fibers
SKU#:
133924
When installation space is extremely limited or the objects to be detected are tiny, fiber-optic sensors are the ideal solution. If it is necessary for even higher requirements to be fulfilled, such as sensing range, temperature resistance, material durability or a flexible mounting process, the intelligent combination of sensors and fibers can provide the perfect solution. A wide range of fibers with application-specific optical heads ensure that every need is met. SICK LBSR40900 7020052 area detection fibers are ideal for detecting objects at any point in the light array and for comparing height differences. Optional mask for limiting the detection area enable even very small objects to be detected.
| Brand | SICK |
|---|---|
| UOM | ea |
| Manufacturer Part Number | 7020052 |
| Manufacturer Alternate Number | LBSR40900 |
| Cable Material | Stainless Steel |
| Material | Glass |
| Sensing Method | Diffuse |
| Special Function | Bifurcated |
| Bending Radius | 19mm |
| Cable Length | 900mm |
| Weight (lbs) | 0.36 |
| Depth (Length) (mm) | 900mm |
