Omron S8VK-R10 10A 5VDC-30VDC 10A Redundancy Unit
SKU#:
420727
Omron understands size is important for panel builders and machine designers, which is why we applied our thermal simulation process and placed the DC output terminals at the top of our S8VK series. This allows internal heat to escape quicker, allowing S8VK-R10 to last longer in applications. Universal input voltage (100 -240 VAC and 90 to 350 VDC) allows S8VK to be used in almost any application.
| Brand | Omron Automation |
|---|---|
| Manufacturer Part Number | S8VK-R10 |
| Manufacturer Alternate Number | S8VKR10 |
| UPC | 4548583425613 |
| Supply Voltage Range | 5VDC - 60VDC |
| Output Voltage DC | 5VDC - 30VDC |
| Output Current | 10A |
| Electrical Connection | Screw Terminals |
| Cooling Type | Natural (Gravity) |
| Enclosure Type | Covered |
| Mounting Type | DIN Rail |
| Series Operation | Yes |
| Parallel Operation | No |
| Standards | UL, UL508, cUL:CSA C22.2, cUR: CSA C22.2, VDE EN50178 |
| Height (mm) | 90mm |
| Depth (Length) (mm) | 110mm |
| Weight (lbs) | 0.40 |
| UOM | ea |
