WAGO 857-400 JUMPFLEX® Signal Conditioners
SKU#:
390050
With a common profile and 6mm wide housing, WAGO 857-400 relays and optocouplers provide a pow-erful compact solution for switching applications. An optional interface adapter plugs into the input or output side, combining eight modules to reduce wiring time and errors. Features include: Pluggable relays or optocouplers, Jumpering capabilities, LED indication, Wide input voltage range (5VAC - 230VAC/5VDC - 230VDC versions), Up to 6 A switching current, Marking options, Can be used with 857 Series signal conditioners.
| Brand | WAGO |
|---|---|
| Manufacturer Part Number | 857-400 |
| Manufacturer Alternate Number | 8570400 |
| UPC | 4045454471293 |
| Input Signal Type | Voltage Current |
| Output Signal Type | Current Voltage |
| Supply Voltage Range | 24VDC |
| Mounting Type | DIN-35 Rail |
| IP Rating | IP20 |
| Electrical Connection | Push-in CAGE CLAMP® |
| Fine-Stranded Conductor Wire Range | 0.34mm2 - 2.5mm2 / 22 - 14 AWG |
| Strip Length | 9mm - 10mm / 0.35 - 0.39 inch |
| Operating Temperature | -25°C - +70°C |
| Height (mm) | 97.8mm / 3.85 inch |
| Width (mm) | 6mm / 0.236 inch |
| Depth (Length) (mm) | 94mm / 3.701 inch |
| Weight (lbs) | 0.08 |
| UOM | ea |
