finder 34.51.7.024.5010 Ultra-Slim PCB Relay
SKU#:
260897
Finder 34 series ultra-slim PCB electromechanical & solid-state relays (EMR & SSR) are compatible with 38 series and 39 series relay interface modules, as well as 93 series bases. 35mm rail mount via screw, screwless or push-in terminal sockets. Finder 34 series relays feature single pole, sensitive DC input circuits (dual AC/DC input drive possible using 93 series sockets) coil in ultra slim 5mm package. 34 series are mainly used in industrial automation for circuit boards within equipment such as vending machines, programmable controllers (PLC interface).
| Brand | finder |
|---|---|
| Manufacturer Part Number | 34.51.7.024.5010 |
| UPC | 8012823217123 |
| Coil Voltage | 24VDC |
| Contact Arrangement | SPDT (1 Form C) |
| Mounting Type | Through-Hole |
| Max. Switching Voltage | 400 VAC |
| Max. Switching Current | 10 A |
| Rated Current | 6A |
| Max. Switching Power(Resistive) | 1,500VA |
| Max. Switching Power (Inductive) | 300VA |
| Minimum Load | 50mW |
| Operating Temperature | -40°C - +85°C |
| RoHS Compliant | Yes |
| Duty Cycles | 1,000,000 |
| Height (mm) | 18.5mm |
| Width (mm) | 28mm |
| Depth (Length) (mm) | 5mm |
| Weight (lbs) | 0.01 |
| UOM | ea |
