finder 60.12.8.240.0040 Plug-in 2-Pole Relay
SKU#:
126220
Finder 60.12.8.240.0040 is a 10A 2-pole (2P) general purpose electromechanical 8/11 pin plug-in relays, 2CO (DPDT - Double pole double throw), 240V AC coil, lockable test button and mechanical indicator. This general purpose relay is compatible with 90 series sockets. Finder 60.12.8.240.0040 is comparable to TE Connectivity CAD11A10-220VAC, Omron MK2P-S-AC220, Carlo Gavazzi RCP8002, IDEC RR2P-UAC240V.
| Brand | finder |
|---|---|
| Manufacturer Part Number | 60.12.8.240.0040 |
| UPC | 8012823044248 |
| Coil Voltage | 24VAC |
| Contact Arrangement | DPDT (2 Form C) |
| Terminal Type | Plug-in, 8 Pin (Octal) |
| Mounting Type | Base/Socket |
| Indicator | Mechanical |
| Test Button | Yes |
| Max. Switching Voltage | 400 VAC |
| Max. Switching Current | 20 A |
| Rated Current | 10A |
| Max. Switching Power(Resistive) | 2,500VA |
| Max. Switching Power (Inductive) | 500VA |
| Minimum Load | 500mW |
| Operating Temperature | -40°C - +70°C |
| RoHS Compliant | Yes |
| Duty Cycles | 1,000,000 |
| Height (mm) | 66.8mm |
| Width (mm) | 36.4mm |
| Depth (Length) (mm) | 32.5mm |
| Weight (lbs) | 0.17 |
| UOM | ea |
